Molecular Sieve
Home > Products > Molecular Sieve > Molecular Sieve 13X

Molecular Sieve 13X

Molecular Sieve 13X

The effective pore opening is 10 Angstrom.It is used for gas deep drying, removal of water and CO2 in cryogenic air sepatation system. It can adsorb any molecules which can be adsorbed by 3A、4A、5A. It also can adsorb the molecules with large critical diameter.



PRODUCTS DESCRIPTION

Type 13X

Composition 1 Na2O: 1 Al2O3 : 2.8 ± 0.2 SiO2 : xH2O

Description The sodium form represents the basicstructure of the type X family, with an effective pore opening in the 910 range. Will not adsorb(C4F9)3N, for example.

Major Applications Commercial gas drying, air plantfeed purification (simultaneous H2O and CO2 removal) and liquid hydrocarbon/natural gas sweetening (H2S and mercaptan removal).

Item

Unit


Shape


Extrudates

Beads

Size

mm

1.5-1.7

3.0-3.3

1.7-2.5

3.0-5.0

Size ratio up to grade

wt%

≥98

≥98

≥98

≥98

Bulk density

Kg/m³

≥620

≥620

≥640

≥640

Abrasion

wt%

≤0.20

≤0.20

≤0.20

≤0.20

Crush strength

N

≥30

≥45

≥30

≥70

Water adsorption

wt%

≥26

≥26

≥26

≥26

CO2 adsorption

wt%

≥18

≥18

≥18

≥18

moisture residual

wt%

≤1.5

≤1.5

≤1.5

≤1.5

13X-2 is used for cryogenic air separation. The adsorption capacity for CO2 and H2O has been futher improved.It has good performance even when CO2 content is low.In the same pressure, the CO2 adsorption capacity is about 22% higher than normal 13X.


Typical Applications:
*Removal of water and CO2 in cryogenic air sepatation system.
*Low regeneration temperature.



"Note:This is normal specification, in case of a particular application, application, please contact 0550-2263726 or by email at info@fznewmaterials.com for technical information."
