250mm Hg, 13X-HP and 13X-APG have little difference. However, 2.2mm Hg, the static adsorption capacity of 13X-HP is 1.78 times more than 13X-APG. In dynamic condition, 450ppm CO, pressure 7kg/cm3 (about 2.317mm Hg), 13X-HPadsorption capacity is about 1.75 times more than 13X-APG. So, only in low partial pressure can 13X-HP play its best performance.
PRODUCTS DESCRIPTION
Advantages:
1. 13X-HP can replace 13X-APG in old cryogenic air separation unit without changing equipment design
2. Smaller column with 13X-HP can reach the same air processing capacity
3. Enlarging air processing capacity when using same amount of 13X-APG
4. Energy Saving: For it can help extending adsorption column transfer time from general 4h to 6h (min), transfer time reduced from regular 6 times/d to 4 times/d, saving great amount of energy especially in electrical heating system
5. Strengthen the equipment stability for reduced transfer time
6. Facilitating examine and repair the equipment without equipment stopping work
7. Increase the molecular sieve life span for reduced regenerative time
Technical Parameter:
Model | 13X-HP | |
Color | Light gray | |
Nominal pore diameter | 10 angstroms | |
Shape | Sphere (ball) | |
Diameter (mm) | 0.4-0.8 | 1.6-2.5 |
Loss on Ignition (wt%.575℃, 1hr) | ≤1.0 | ≤1.0 |
Bulk density (g/ml) | ≥0.62 | ≥0.62 |
Crushing strength (N) | / | ≥30/piece |
Static H2O capacity (wt% RH60%,25℃) | ≥30 | ≥30 |
Static CO2 capacity(wt% 250mmHg, 25℃) | ≥19.8 | ≥19.8 |
Attrition (wt%) | ≤0.2 | ≤0.2 |
Particle Ration (%) | ≥95 | ≥97 |
N2 capacity(ml/g,) | ≥8 | ≥8 |
N2/O2 Selectivity(a,) | ≥3 | ≥3 |
More Detailes:
1. Synonym: Cryogenic air separation unit, UOP APG-III, molecular sieve 13X-APG
2. CAS NO.: 1318-02-1
Application:
Oxygen Molecular Sieve is widely used in
Industrial oxygen generating systems
Scuba oxygen tanks and bottles
Home oxygen generator equipment
Hospital oxygen supply systems
Aquaculture oxygen systems
Portable oxygen generators
Emergency oxygen systems
Ozone generators
PSA (pressure swing adsorption) oxygen generators
Molecular sieve 13X-HP is used in cryogenic air separation pre-purification unit
Stroage:
Keep molecular sieve 13X-HP is stored in an air tight container until ready for use to avoid unintended moisture adsorption. Avoid direct sunlight!
"Note：This is normal specification, in case of a particular application, application, please contact us by email at info@fznewmaterials.com for technical information."
